Inline Network Port Replicator Tap Aggregation with Smart Bypass

Product Details

Place of Origin: China

Brand Name: NetTAP®

Certification: CCC, CE, RoHS

Model Number: NT-iMXTAP-24G-D

Payment & Shipping Terms

Minimum Order Quantity: 1 SET

Price: Can Discuss

Packaging Details: Outer Carton plus Inner Foam

Delivery Time: 1-3 Working Days

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 100 sets per month

Get Best Price
Contact Now
Specifications
High Light:

port replicator tap aggregation

,

Inline Network Port Replicator Tap

,

Smart Bypass Port Replicator Tap

Port Mirror:
Port Replicator Tap
Network Tap:
Tap Replicator And Tap Aggregator
Deployment Mode:
Inline, Out Of Band, SPAN
Data Filtering:
L2-L4 Layer Message Filter Matching
Applications:
Tap Replicator 1-> N Ports, Tap Aggregator N -> M Ports
Solutions:
Network Port Replicator
Port Mirror:
Port Replicator Tap
Network Tap:
Tap Replicator And Tap Aggregator
Deployment Mode:
Inline, Out Of Band, SPAN
Data Filtering:
L2-L4 Layer Message Filter Matching
Applications:
Tap Replicator 1-> N Ports, Tap Aggregator N -> M Ports
Solutions:
Network Port Replicator
Description
Inline Network Port Replicator Tap Aggregation with Smart Bypass

Inline Network Port Replicator Tap Aggregation with Smart Bypass

1. Overviews

  • Network Traffic replication, aggregation and forwarding integrated
  • Flexible deployment of multiple modes in both Inline and SPAN Bypass mode
  • Support gigabit inline serial connection electrical port and SFP gigabit optical interface
  • Support Ethernet package independence
  • Supports powerful packet filtering functions
  • Support for custom streaming
  • Support smart BYPASS technology to ensure fast link recovery
  • Support console, IP/WEB, SNMP, Syslog, SSH and other management
  • Support dual power redundancy

Inline Network Port Replicator Tap Aggregation with Smart Bypass 0


2. Intelligent Traffic Processing Abilities​


Inline Network Port Replicator Tap Aggregation with Smart Bypass 1ASIC Chip Plus TCAM CPU

24Gbps intelligent traffic processing capabilities



Inline Network Port Replicator Tap Aggregation with Smart Bypass 2Data Filtering

Supported L2-L7 packet filtering matching, such as SMAC, DMAC, SIP, DIP, Sport, Dport, TTL, SYN, ACK, FIN, Ethernet type field and value, IP protocol number, TOS, etc. also supported flexible combination of up to 2000 filtering rules.



Inline Network Port Replicator Tap Aggregation with Smart Bypass 3Load Balance

Supported load balance Hash algorithm and session-based weight sharing algorithm according to L2-L7 layer characteristics to ensure that the port output traffic dynamic of load balancing



Inline Network Port Replicator Tap Aggregation with Smart Bypass 4Real-time Traffic Trend Monitoring
Supported real-time monitoring and statistics on port-level and policy-level data traffic, to show the RX / TX rate, receive / send bytes, No., RX / TX the number of errors, the maximum income / hair rate and other key indicators.

Inline Network Port Replicator Tap Aggregation with Smart Bypass 5NetTAP® Visibility Platform
Supported NetTAP® Matrix-SDN Visual Control Platform Access

Inline Network Port Replicator Tap Aggregation with Smart Bypass 61+1 Redundant Power System(RPS)
Supported 1+1 Dual Redundant Power System



Inline Network Port Replicator Tap Aggregation with Smart Bypass 7
3. Typical Features

Inline Network Tap Embedded Tap Replicator and Tap Aggregator with Smart Bypass is an online gigabit TAP device for freely guiding output of gigabit Ethernet link flow acquisition, aggregation, shunt, load balancing, etc.

Inline Network Tap Embedded Tap Replicator and Tap Aggregator with Smart Bypass can forward, replicate or aggregate the traffic of each online serial connection and SPAN port based on flexible control strategy, and can accurately customize the traffic type of output interface, so as to further meet the deployment requirements of various network security devices, protocol analysis, signaling analysis and other traffic monitoring.

Hybrid Deployment Traffic Acquisition or Traffic Capturing

Support in- line serial acquisition

Support SPAN port image acquisition

Support optical fiber spectral acquisition



Rich Interface

Supports 12 inline serial connection gigabit ports

Supports 12 SFP gigabit optical interfaces

Supports all port line speed work without losing packets



Rich Flow(Traffic) Processing Mechanism

Supports 1 -> N, N -> M, channel flow replication and aggregation

Supports L2-L4 layer message filter matching, including SIP, DIP, SP, DP, protocol number, input interface and other elements of the flexible combination of filtering conditions

Supports multiple rule combinations

Supports the number of rules above 2K

Supports black and white list filtering rules



Bypass Protection

Supports serial port link status detection synchronization

Supports Bypass speed switch, no flash in link state



Load Balancing

Supports dynamic load balancing or custom load balancing

Supports IP five - tuple - based hash load balancing calculation

Supports any binding of load balancing output port groups



Powerful and Easy to Use

Easy to use WEB configuration interface

Status monitoring: power supply, system status, interface rate, interface LINK status, port transceiver packet and other information can be visually displayed.

Fully compatible with intrusion detection system, protocol analyzer, RMON probe, network audit system and other applications.



Inline Network Port Replicator Tap Aggregation with Smart Bypass 8NT-iMXTAP-24G-D Network TAP NPB.pdf


4. Specifications

Inline Network Tap Embedded Tap Replicator and Tap Aggregator with Smart Bypass
Network Interface GE Electrical Ports 12*10/100/1000M BASE-T Ports
SFP slots 12*SFP slot ports, support GE Optical/Electrical Module
Deployment Mode Inline mode support max 6*10/100/1000M BASE-T Inline mode
SPAN monitoring input support max 23*SPAN inputs
Monitoring Output support max 23*monitoring outputs
Functions Total QTYs interface 24
Traffic replication / aggregation / distribution support
Inline mode and SPAN monitoring support
Link QTYs supporting Mirror replication / aggregation

1 -> N link traffic replication (N <23)

N-> 1 link traffic aggregation (N <23)

G Group(M-> N Link) traffic replication and aggregation [G * (M + N) <24]

Up/Down Traffic Aggregation support
Up/Down Traffic Monitoring support
Distribution based on traffic identification support
Distribution based on IP / protocol / port Five tuple traffic identification support
Distribution strategy based on protocol header the key labeled traffic identifies support
Support Ethernet encapsulation independence support
BYPASS Function(Inline mode) support

BYPASS Switch Time

(Inline mode)

< 150ms
Link Reflect (Inline mode) support
Link Safe Switch (Inline mode) support
CONSOLE Network Management support
IP/WEB Network Management support
SNMP V1/V2C Network Management support
TELNET/SSH Network Management support
SYSLOG Protocol support
User authentication function Password authentication based on user name
Electric(1+1 Redundant Power System-RPS) Rated supply voltage AC110-240V/DC-48V (Optional)
Rated power frequency 50HZ
Rated input current AC-3A / DC-10A
Rated power function 100W
Environment Operating Temperature 0-50℃
Storage Temperature -20-70℃
Operating Humidity 10%-95%, Non-condensing
User Configuration Console Configuration RS232 interface,115200,8,N,1
Password authentication support
Rack Height Rack space (U) 1U 485mm*44.5mm*350mm
